Stanford University Studys Suggests Carbon Capture Can Cause More Harm Than Good

14 Nov 2019  by Taylor Kubota, Stanford Universi

One proposed method for reducing carbon dioxide (CO2) levels in the atmosphere—and reducing the risk of climate change—is to capture carbon from the air or prevent it from getting there in the first place. However, research from Mark Z. Jacobson at Stanford University, published in Energy and Environmental Science, suggests that carbon capture technologies can cause more harm than good.

"All sorts of scenarios have been developed under the assumption that carbon capture actually reduces substantial amounts of carbon. However, this research finds that it reduces only a small fraction of carbon emissions, and it usually increases air pollution," said Jacobson, who is a professor of civil and environmental engineering. "Even if you have 100 percent capture from the capture equipment, it is still worse, from a social cost perspective, than replacing a coal or gas plant with a wind farm because carbon capture never reduces air pollution and always has a capture equipment cost. Wind replacing fossil fuels always reduces air pollution and never has a capture equipment cost."

Jacobson, who is also a senior fellow at the Stanford Woods Institute for the Environment, examined public data from a coal with carbon capture electric power plant and a plant that removes carbon from the air directly. In both cases, electricity to run the carbon capture came from natural gas. He calculated the net CO2 reduction and total cost of the carbon capture process in each case, accounting for the electricity needed to run the carbon capture equipment, the combustion and upstream emissions resulting from that electricity, and, in the case of the coal plant, its upstream emissions. (Upstream emissions are emissions, including from leaks and combustion, from mining and transporting a fuel such as coal or natural gas.)

Common estimates of carbon capture technologies—which only look at the carbon captured from energy production at a fossil fuel plant itself and not upstream emissions—say carbon capture can remediate 85-90 percent of carbon emissions. Once Jacobson calculated all the emissions associated with these plants that could contribute to global warming, he converted them to the equivalent amount of carbon dioxide in order to compare his data with the standard estimate. He found that in both cases the equipment captured the equivalent of only 10-11 percent of the emissions they produced, averaged over 20 years.

This research also looked at the social cost of carbon capture—including air pollution, potential health problems, economic costs and overall contributions to climate change—and concluded that those are always similar to or higher than operating a fossil fuel plant without carbon capture and higher than not capturing carbon from the air at all. Even when the capture equipment is powered by renewable electricity, Jacobson concluded that it is always better to use the renewable electricity instead to replace coal or natural gas electricity or to do nothing, from a social cost perspective.

Given this analysis, Jacobson argued that the best solution is to instead focus on renewable options, such as wind or solar, replacing fossil fuels.

Efficiency and upstream emissions

This research is based on data from two real carbon capture plants, which both run on natural gas. The first is a coal plant with carbon capture equipment. The second plant is not attached to any energy-producing counterpart. Instead, it pulls existing carbon dioxide from the air using a chemical process.

Jacobson examined several scenarios to determine the actual and possible efficiencies of these two kinds of plants, including what would happen if the carbon capture technologies were run with renewable electricity rather than natural gas, and if the same amount of renewable electricity required to run the equipment were instead used to replace coal plant electricity.

While the standard estimate for the efficiency of carbon capture technologies is 85-90 percent, neither of these plants met that expectation. Even without accounting for upstream emissions, the equipment associated with the coal plant was only 55.4 percent efficient over 6 months, on average. With the upstream emissions included, Jacobson found that, on average over 20 years, the equipment captured only 10-11 percent of the total carbon dioxide equivalent emissions that it and the coal plant contributed. The air capture plant was also only 10-11 percent efficient, on average over 20 years, once Jacobson took into consideration its upstream emissions and the uncaptured and upstream emissions that came from operating the plant on natural gas.

Due to the high energy needs of carbon capture equipment, Jacobson concluded that the social cost of coal with carbon capture powered by natural gas was about 24 percent higher, over 20 years, than the coal without carbon capture. If the natural gas at that same plant were replaced with wind power, the social cost would still exceed that of doing nothing. Only when wind replaced coal itself did social costs decrease.

For both types of plants this suggests that, even if carbon capture equipment is able to capture 100 percent of the carbon it is designed to offset, the cost of manufacturing and running the equipment plus the cost of the air pollution it continues to allow or increases makes it less efficient than using those same resources to create renewable energy plants replacing coal or gas directly.

"Not only does carbon capture hardly work at existing plants, but there's no way it can actually improve to be better than replacing coal or gas with wind or solar directly," said Jacobson. "The latter will always be better, no matter what, in terms of the social cost. You can't just ignore health costs or climate costs."

This study did not consider what happens to carbon dioxide after it is captured but Jacobson suggests that most applications today, which are for industrial use, result in additional leakage of carbon dioxide back into the air.

Focusing on renewables

People propose that carbon capture could be useful in the future, even after we have stopped burning fossil fuels, to lower atmospheric carbon levels. Even assuming these technologies run on renewables, Jacobson maintains that the smarter investment is in options that are currently disconnected from the fossil fuel industry, such as reforestation—a natural version of air capture—and other forms of climate change solutions focused on eliminating other sources of emissions and pollution. These include reducing biomass burning, and reducing halogen, nitrous oxide and methane emissions.

"There is a lot of reliance on carbon capture in theoretical modeling, and by focusing on that as even a possibility, that diverts resources away from real solutions," said Jacobson. "It gives people hope that you can keep fossil fuel power plants alive. It delays action. In fact, carbon capture and direct air capture are always opportunity costs."
